Martin Audio W8VDQ Line Array Speaker

The Martin Audio W8VDQ combines line array and differential dispersion technologies to provide an advanced solution to the requirement of even coverage over wide angles and throw distances. Short throw horizontal dispersion is 120º, narrowing to 100º as throw increases. The vertical differential directivity, VDQ, creates progressively more HF output as throw distance increases. The resultant dispersion pattern is ideally suited to covering audiences located on flat or gradually sloping surfaces.

  • Compact, three-way, differential directivity system
  • Hybrid® quad 8” (200mm) LF + MF configuration
  • LF + MF - 102dB @ 2.83V, 1m (single cabinet)
  • Quad 1” (25mm) HF, all horn loaded - 106dB @ 2.83V, 1m
  • Max 131dB continuous, 137dB peak output
  • Consistent 100º long throw, 120º short throw
  • (-6dB) horizontal mid and HF pattern control
  • 30º vertical differential directivity, VDQ
  • Passive or bi-amp operation
  • Optional yoke/spigot mount adaptor
  • Compatible with WS218 sub-woofers

Martin Audio W8VDQ

DATASHEET

TYPE Three-way passive/biamp
FREQUENCY RESPONSE (5) 60Hz-18kHz ± 3dB
DRIVERS 2 x 8” (200mm), 2” (50mm) voice coil, reflex- loaded direct radiators
2 x 8” (200mm), 2” (50mm) voice coil, neodymium magnet, front horn loaded, rear reflex loaded drivers
4 x 1” (25mm) exit HF compression drivers, horn loaded
RATED POWER (2) LF+MF: 800W AES, 3200W peak
HF: 150W AES, 600W peak
Passive: 800W AES, 3200W peak
RECOMMENDED AMPLIFIER MA5.2K / MA3.0
SENSITIVITY (6) LF+MF: 102dB
HF: 106dB
Passive: 101dB, rising to 105dB at HF
MAXIMUM SPL (calculated @ 1m) 131dB continuous,
137dB peak
NOMINAL IMPEDANCE LF+MF: 6 ohms
HF: 6 ohms
Passive: 6 ohms
DISPERSION (-6dB) 100-120º horizontal, 30º vertical (VDQ)
CROSSOVER 300Hz passive, 2.2kHz active or passive
ENCLOSURE 70 litre, multi-laminate birch ply
FINISH Textured black paint
PROTECTIVE GRILLE Black perforated steel
CONNECTORS 2 x Neutrik NL4
PIN CONNECTIONS LF+MF: 1+,1-
HF: 2+,2-
Passive: 1+,1-
FITTINGS 9 x M10 inserts
Pole mount socket
2 x bar handles
DIMENSIONS (W) 628mm x (H) 506mm x (D) 369mm
(W) 24.7ins x (H) 19.9ins x (D) 14.6ins
WEIGHT 47kg (103.5lbs)

Martin Audio W8VDQ Hire code - GSPS003

Week Hire £81.00 (EX-VAT)
Day Hire £27.00 (EX-VAT)
